TP5100 Charger PCB | 2-Cell 8.4V / Single 4.2V, 2Amp

Key Features

• Dual-Mode Charging: The TP5100 Charger PCB supports both 2-cell (8.4V) and single-cell (4.2V) lithium battery charging. You can easily switch between modes to suit your battery configuration.
• High Charging Current: With a maximum charging current of 2A, this module provides fast and efficient charging for your lithium-ion or lithium-polymer batteries.
• Intelligent Charging Algorithm: Equipped with intelligent charging technology, it supports constant current and constant voltage (CC-CV) modes, ensuring safe and effective charging.
• LED Status Indicators: The module includes dual LEDs to indicate the charging process—red for charging and green for fully charged—offering convenient status updates.
• Compact Design: Its small size makes it ideal for integration into space-constrained projects or custom battery management systems.
• High Efficiency: The TP5100’s advanced design minimizes energy loss, ensuring high efficiency and reduced heat generation during charging.
• Protection Features: Built-in protection against overcurrent, overvoltage, and reverse polarity keeps your batteries and connected devices safe.

Applications

Battery Charging Systems: Perfect for charging 1S (4.2V) or 2S (8.4V) lithium-ion or lithium-polymer batteries in DIY projects or custom devices.

Power Banks: Integrate this module into portable power banks to recharge lithium battery packs efficiently.

DIY Electronics: Use the TP5100 in custom electronics to create reliable and fast-charging solutions for various gadgets.

Solar-Powered Systems: Incorporate the module into solar-powered setups to manage battery charging and energy storage.

RC Models and Robotics: Ideal for charging lithium batteries in remote-controlled vehicles, drones, or robotics applications.

Why Choose This Charger PCB?

• Dual Compatibility: Supports both single-cell and dual-cell batteries, making it versatile for various applications.
• Fast and Reliable Charging: The 2A charging current provides quick and efficient power delivery.
• Safety Assured: Built-in protections ensure safe operation, preventing damage to batteries and connected devices.
• Compact and Easy to Use: Its small size and clear LED indicators make it user-friendly and easy to integrate.
• Cost-Effective Solution: Offers high performance at an affordable price, making it perfect for hobbyists and professionals alike.

Order Now

Upgrade your charging setup with the TP5100 Charger PCB | 2-Cell 8.4V / Single 4.2V, 2Amp. Whether you’re building a power bank, charging system, or solar project, this module provides reliable and efficient charging for your batteries.

Explore our store for additional components, modules, and accessories to complement your projects. Ideal for students, hobbyists, and engineers!

Note

For optimal performance, use proper heat dissipation and follow the recommended input voltage range. Ensure correct wiring to avoid damage to the module or batteries.

Visit our YouTube Channel for step-by-step tutorials, project ideas, and tips to make the most of your TP5100 Charger PCB!
