XL6009 DC-DC Boost Converter Step-Up Power Module

XL6009 DC-DC Boost Converter Step-Up Power Module

Rs. 64.90
Rs. 99.00 Rs. 64.90
Sale Sold out
Shipping calculated at checkout.

XL6009 DC-DC Boost Converter Module boosts low voltages to higher adjustable output. Ideal for battery projects, LED strips, DIY power supplies, Arduino and electronics prototyping.

Secure checkout • Quality checked • Safe packaging for delivery

View full details

The XL6009 Step-Up (Boost) Converter Module is a powerful and efficient DC-DC voltage booster designed for makers, students, and engineers who need a stable higher output voltage from a lower input source. Powered by the XL6009 switching regulator, it offers higher efficiency and improved performance compared to older LM2577/LM2587 designs.

With a wide input range, smooth output adjustment, and built-in power indicator, this module is ideal for DIY power banks, LED drivers, battery projects, and hobby electronics.

🟧 Key Features

  • High-Efficiency Boost Converter powered by XL6009 IC
  • Wide Input Range supports 3V to 35V DC
  • Adjustable Output Voltage from 5V to 55V (via onboard potentiometer)
  • High Conversion Efficiency up to 94%
  • Built-In Schottky Diode for improved stability
  • Onboard Heat Sink on the regulator for better thermal management
  • LED Indicator for power ON status
  • Compact & Easy to Integrate in DIY electronics and embedded projects

🟧 Technical Specifications

  • Input Voltage: 3V – 35V DC
  • Output Voltage: 5V – 55V DC (adjustable with potentiometer)
  • Output Current: Up to 3A (peak), 2A recommended continuous
  • Efficiency: Up to 94% (varies with input/output conditions)
  • Switching Frequency: 400 kHz
  • Module IC: XL6009 DC-DC Boost Regulator
  • Protection: Input reverse polarity protection (module dependent)
  • Indicator: Power LED
  • Connections:VIN+ VIN− VOUT+ VOUT−
  • Dimensions: Approx. 42 × 20 × 14 mm

🟧 Package Includes

  • 1 × XL6009 DC-DC Boost Converter Step-Up Power Module

🟧 Ideal For

  • DIY power banks
  • Boosting 3.7V Li-ion battery to 5V / 9V / 12V outputs
  • LED strip driving
  • RC hobbies and robotics
  • Charging circuits (with proper controls)
  • Step-up power supply for prototyping
  • Home and school electronics projects
